Hikvision Face picture comparison 4K 2HDD AI 8CH NVR DS-7608NXI-K2
| n Specification | ||
| Intelligent Analytics | ||
| AI by Device | Facial recognition, perimeter protection, motion detection 2.0 | |
| AI by Camera | Facial recognition, perimeter protection, throwing objects from building, motion detection2.0, ANPR, VCA | |
| Facial Recognition | ||
| Facial Detection and Analytics | Face picture comparison, human face capture, face picture search | |
| Face Picture Library | Up to 16 face picture libraries, with up to 20,000 face pictures in total (each picture ≤ 4 MB, total capacity ≤ 1 GB) | |
| Facial Detection and Analytics Performance | 1-ch, 8 MP | |
| Face Picture Comparison | 4-ch | |
| Motion Detection 2.0 | ||
| By Device | All channels, 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarm | |
| By Camera | All channels | |
| Perimeter Protection | ||
| By Device | 2-ch, 4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm | |
| By Camera | All channels | |
| Video and Audio | ||
| IP Video Input | 8-ch | |
| Incoming Bandwidth | 80 Mbps | |
| Outgoing Bandwidth | 160 Mbps | |
| HDMI Output | 1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz | |
| VGA Output | 1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz | |
| Video Output Mode | HDMI/VGA independent output | |
| CVBS Output | N/A | |
| Audio Output | 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input) | |
| Two-Way Audio | 1-ch, RCA (Linear, 1 KΩ) | |
| Decoding | ||
| Decoding Format | H.265/H.265+/H.264+/H.264 | |
| Recording Resolution | 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF | |
| Synchronous playback | 8-ch | |
| Decoding Capability | AI on: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps) AI off: 2-ch@12 MP (30 fps)/3-ch@8 MP (30 fps)/6-ch@4 MP (30 fps)/12-ch@1080p (30 fps) | |
| Stream Type | Video, Video & Audio | |
| Audio Compression | G.711ulaw/G.711alaw/G.722/G.726/AAC | |
| Network | ||
| Remote Connection | 128 | |
| API | ONVIF (profile S/G); SDK; ISAPI | |
| Compatible Browser | IE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version | |
| Network Protocol | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS | |
| Network Interface | 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface | |
| Auxiliary Interface | ||
| SATA | 2 SATA interfaces | |
| Capacity | Up to 10 TB capacity for each HDD | |
| USB Interface | Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0 | |
| Alarm In/Out | 4/1 | |
| General | ||
| GUI Language | English, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian | |
| Power Supply | 12 VDC, 3.3 A | |
| Consumption | ≤ 15 W (without HDD) | |
| Working Temperature | -10 °C to 55 °C (14 °F to 131 °F) | |
| Working Humidity | 10% to 90% | |
| Dimension (W × D × H) | 385 mm × 315 mm × 52 mm (15.2″× 12.4″ × 2.0″) | |
| Weight | ≤ 1 kg (without HDD, 2.2 lb.) | |
alarm inout nvr
1hdd wizsense network video recorder
channels 12mp 4k ultra hd
What is the spec of DS 7608NI K2?
What is the spec of DS 7608NXI K2 8P? please visit https://lankatek.com
What is the difference between Hikvision NVR 76 and 77?
the number of SATA interfaces; 76 series has 2 SATA interfaces while the 77 family has 4 allowing for double the maximum memory capacity.
